The Julian Street Inn – Shelter for the Homeless: Building Permit drawings of Set D “Dining Hall” – Structural system
1) Precast concrete truss

10/07/1987

Structural Design, Permit Drawing, Elevation

Content of

Drawing 1 Items

The Julian Street Inn - Shelter for the Homeless: Building Permit drawings of Set D "Dining Hall" - Structural system 2 2) Gunite concrete truss 10/07/1987

Structural Design, Permit Drawing, Elevation

Two drawing sheets of the concrete truss with dimensions and notes on reinforcement. The first titled “Precast Concrete Truss” is an architectural drawing included the the 1987 building permit. The second is a structural drawing titled “Gunite Concrete Truss” and ...
