Berryessa Terraced House: Wooden post and beam, load bearing structural frame combined with sprayed concrete exterior walls – Design Development Drawings
Framing plan

15/11/1981

Design Development, Axonometric, Framing Plan

Designers:

Christopher Alexander, Artemis Anninou, Berkeley, CA, U.S.A.

Medium:

Original on Vellum

Size:

Extract from 24"x30 1/2" drawing

Scale:

1/4"=1', 1/2"=1'

Content of

Drawing

Berryessa Terraced House: Wooden post and beam, load bearing structural frame combined with sprayed concrete exterior walls - Design Development Drawings 15/11/1981

Design Development, Axonometric, Framing Plan

Designers:

Christopher Alexander, Artemis Anninou, Berkeley, CA, U.S.A.

Medium:

Original on Vellum

Size:

Extract from 24"x30 1/2" drawing

Scale:

1/4"=1', 1/2"=1'

The framing plan of the two main volumes of the house, and an axonometric of framing connections, designed and built for vertical forces .
