Sala House: Presentation Drawings – Building section with details

Three-story tower, 20 feet by 20 feet in plan on each floor, on a wooded, sloping site. The interior structure of the house is wood post and beam with pine panelling and hand-painted surfaces, and the exterior is a red ...

Focusing primarily on the pure beauty of the geometric order, which comes, above all, from the building structure (columns, walls, beams, vaults and so forth), specifically from the aperiodic grids which form the abstract underpinning of the building structure.

Five drawings with construction details of the timber frame.

Two drawings of the concrete bracket.

Building section with framing plans, window sections and other wood framing details.
