Sweet Potatoes Offices and Workshops: Thick Wall with Four Panels – Preliminary Design Drawings
3 2) Wall horizontal section

01/03/1985

Preliminary Design, Floor Plan, Section, Elevation

Two sheets of pencil hardline preliminary drawings with dimensions of a thick wall made of four panels, three of them with built-in storage and shelfing elements; it was designed for a part of the long wall of the production room, but was not implemented. .

Designers:

Christopher Alexander, Artemis Anninou, Gary Black, Berkeley, CA, U.S.A.

Medium:

Original on Tracing Paper

Size:

8 1/2"x22"

Scale:

1"=1'

Download File

Content of

Construction Innovation 1 Items

Sweet Potatoes Offices and Workshops: Thick Walls 1985

Construction System, Monocoque Construction

Created by:

Christopher Alexander, Artemis Anninou, Gary Black

A custom made set of thick wall components, all premanufactured with the same height, standardized thickness, and a variety of standardized lengths, to enable the realization of a variety of rooms, as they were laid out by the users. ...

References

Drawings 1 Items

Haworth New Office Furniture System: Thick Wall with Four Panels- Design Development Drawings 01/12/1985

Construction Innovation, Design Development, Axonometric, Section, Elevation

Designers:

Christopher Alexander, Artemis Anninou, Gary Black, Berkeley, CA, U.S.A.

Medium:

Original on Vellum

Size:

8 1/2"x11", 10"x13"

Scale:

1 1/2"=1'

Digitized

Nine sheets of ink hardline drawings of the thick wall made of four panels, three of them with built-in storage and shelfing elements. A version of it was built in one of the Sweet Potatoes production room walls, adjusted to ...
