Photograph

Tokyo International Forum: Photographs of drawings

01/04/1989

Drawing

Photograph of drawing in 1:200, with the floor plan and section of the main Convention Hall, an enormous room, 50 meters by 70 meters, whose position defined the organization of the entire design.

Photographer:

Christopher Alexander/C.E.S., Martinez, CA, U.S.A.

Source:

Digital, Print, Slide

Characteristics:

7"x11", B&W

Content of

Project

Tokyo International Forum: Conference Center for City of Tokyo 1989

3-5-1 Marunouchi, Chiyoda-ku, Tokyo, Japan

Civic, Designed , Invited Competition, Not built

Client:

Tokyo International Forum Project Office, Bureau of Citizens and Cultural Affairs, Tokyo Metropolitan Government

C.E.S. staff:

Christopher Alexander, Artemis Anninou, Hansjoachim Neis, Ingrid Fiksdahl-King, Eleni Coromvli, Gary Black

Project cost:

Expected construction cost: $750,000,000

Project stages:

Preliminary Design drawings Construction innovation methods

Invited design competition entry for a complex of conference halls, auditoria, exhibition halls, and other public facilities at a central site in downtown Tokyo, occupied by the City Hall, which was to be razed to make way for this project. ...
